Construction Materials Metal Mesh Structural Stay-In-Place Formwork System
Production description
Making sure to keep up with the new methods of construction, we are pleased to offer our clients the new construction system. This construction system combines both steel reinforcement and casing for pouring concrete in a stable way for concrete buildings. It is also an international system approved from The Housing and Building National Research Center. The walls and the floor are concreted together at same time, the casing is delivered and installed with the shape and the dimensions according to the Client’s design.
These panels are typically made from high-quality materials such as metal, or synthetic composites, ensuring durability and longevity. They come in various designs, textures, and finishes, allowing for a wide range of customization options to suit different aesthetic preferences and functional requirements.
Product specifications
| Name |
Galvanized Rib Lath Cement Pouring Formwork Structure |
| Material |
Galvanized steel |
| Size |
1.1m*3m or customized |
| Weight |
11kg/sqm |
| Rib lath |
0.4mm thickness |
| C-profiles |
0.6mm thickness |
| Connectors |
1.5mm thickness, 20*19mm |
| Rebar |
5mm diameter, 700N/mm² traction strength |
| Feature |
Long lasting, enhance strength, light weight, save time |
| MOQ |
1pcs |
Product advantage
Consists of galvanized or stainless steel welded mesh on both sides.
Acts as permanent reinforcement for concrete.
Facilitates bonding with the poured concrete, enhancing structural strength.
No need to remove the formwork after concrete curing.
Reduces construction time and labor costs.
The central void between the meshes is filled with concrete.
Provides strength similar to traditional reinforced concrete walls.
Product application
Used in residential, commercial, and industrial buildings.
Ideal for fast construction of vertical structural walls.
Provides both formwork and reinforcement in one system.
Suitable for soil or slope retention in civil engineering.
Reinforced concrete with mesh gives it high resistance to lateral earth pressure.
Waterproofing membranes can be applied directly to mesh panels before backfilling.
Can be installed directly on footings or slabs.
