High Adhesion Building Panels Expanded Rib Lath For Formwork System
Production description
Hy-Ribbed Formwork is also known as Permanent Formwork, expanded Formwork. It is used as the consumable template. The edges of the open of the mesh will be inset in the concrete when the concrete pouring behind the formwork. That will be a mechanical wedge to link with
the block. The quality of the joint can be strictly controlled. The strength of the adhesion and shearing can be equal to the excelletn rough cut stitching. There is no drilling, plucking and other process needed when do the secondary pouring. It can shor the construction time and at the same time make the concrete stronger.
Product specifications
| Name |
Galvanized Rib Lath Cement Pouring Formwork Structure |
| Material |
Galvanized steel |
| Size |
1.1m*3m or customized |
| Weight |
11kg/sqm |
| Rib lath |
0.4mm thickness |
| C-profiles |
0.6mm thickness |
| Connectors |
1.5mm thickness, 20*19mm |
| Rebar |
5mm diameter, 700N/mm² traction strength |
| Feature |
Long lasting, enhance strength, light weight, save time |
| MOQ |
1pcs |
Product advantage
1.Excellent Bond with Concrete
The mesh and rib structure allows concrete to pass through and interlock, resulting in strong mechanical bonding between the concrete and the lath.Reduces risk of surface delamination or poor adhesion.
2.Lightweight and Easy to Handle
Much lighter than traditional formwork panels like plywood or steel plates.Easier to cut, shape, and install, especially in complex or curved structures.
3.No Need for Formwork Removal
Acts as permanent formwork—it stays in place after the concrete sets.
Saves labor and time because there's no need for stripping or dismantling.
4.Cost-Efficient
Reduces the need for traditional formwork materials and labor.
Minimizes wastage and handling costs.
Product application
Diamond lath mesh permanent formwork can be widely used in including theprotection of machinery equipment, handicraft manufacturing, shelves, heavy machinery, work platforms, walkways,ships as well as building material for plastering base, structural formwork and fireproofing construction.
About us
Founded in 2000, our workshop started as a 10-person team under the leadership of Mr. CUI (Our General Manager). By 2010, we expanded our workshops to 5000 sqm with complete departments including Production, Sales, After-sales, Technology, Research and Development, Procurement, and Design.
Today, Anping Velp Wire Mesh Products Co., Ltd has developed an enviable reputation for research, development, and as the premier option for expanded metal, perforated metal mesh, safety walkway grating, stainless steel 304/316 weave mesh, and building stucco mesh products in China.
