Product Details:

Place of Origin: Hebei,China
Brand Name: WANNUO
Certification: ISO9001
Model Number: ANPINGWANNUO-154

Payment & Shipping Terms:

Minimum Order Quantity: 20GP
Packaging Details: the packing of high quality anti-skid galvanized perforated metal mesh plate for sale is steel pallet or as custom made
Delivery Time: According to the requirment
Supply Ability: 1000 Square Meter/Square Meters per Day high quality anti-skid galvanized perforated metal mesh
Contact Now
Detailed Product Description
Material: Steel Application: Ladder Rungs
Model Number: Customized Thickness: 1.0-3.0mm
Width: ≤1000mm Length: ≤4000mm
Holes: Alligator Mouth Type,so On Weave Style: Stamping



Economical Grip Strut Plank Grating 1.0-3.0mm Thick For Ladder Rungs Abrasive Nosing



The Product Description:

Diamond-Strut safety grating is made of carbon steel, stainless steel or aluminum by cold forming. It can be divided into three types: plank grating, stair treads and ladder rungs.

There are two types of surface: serrated and smooth. Serrated surface prevents people from falling. And smooth surface can be used in the situations where required smooth. In addition, diamond-shaped openings allow for drainage of fluids and debris.

Due to these excellent performances, diamond-strut safety grating is widely used as floor, walkway, stair treads and platform in industrial, civil and commercial buildings.

The serrated surface on this metal grating is designed in an open diamond pattern. This metal grating allows drainage of fluids, mud, chips and other accident-causing debris. The 24” wide Grip Strut walking grating has 4-1/2" toe boards formed into the panel, Grip Strut™ safety metal grating walkways meet OSHA requirements for toe boards on elevated structures

Manufactured with a standard serrated diamond matrix, Super Grip provides exceptional slip-resistance in all directions. A plain surface diamond matrix is available on special order.



Plank Widths:



  • 2 Diamond - 4-3/4" wide
  • 3 Diamond - 7" wide
  • 4 Diamond - 9-1/2" wide
  • 5 Diamond - 11-3/4" wide
  • 8 Diamond - 18-3/4" wide
  • 10 Diamond - 24" wide



Channel Depths:



  • 14 gauge Steel - 1-1/2", 2", 2-1/2"
  • 12 gauge Steel - 1-1/2", 2", 2-1/2", 3"
  • 12 gauge (.080) Aluminum - 2"
  • 10 gauge (.100) Aluminum - 2"
  • 16 gauge Stainless Steel - 2"



Stock Lengths:

  • 10’-0 and 12’-0



Specification of Diamond-Strut Safety Grating
MaterialSpan (inches)GaugeDepthStandard stair treadsStair treads with nosing





Steel

Up to 30



14 or 12 gauge

1-1/2"Diamonds (4-3/4")
Diamonds (7")
Diamonds (9-1/2")
Diamonds (11-3/4")



Diamonds (8-1/8")
Diamonds (10-1/2")

30–361-1/2"
36–421-1/2"
42–482"
AluminumUp to 420.080"



2"

Up to 480.100"
Stainless steelUp to 30316L 16 gauge



2"

Up to 36304L 16 gauge



Specification



Material

Pre-galvanized carbon steel: 12 and 14 gauge.

HRPO carbon steel: 12 and 14 gauge.

Aluminum 5052-H32: 10 and 12 gauge, 0.08" or 0.10" thickness.

Stainless steel 304 or 316L: 16 gauge.











 Type

· Diamond-Strut plank grating

· Width

· 2-Diamond: 4-3/4".

· 3-Diamond: 7".

· 4-Diamond: 9-1/2".

· 5-Diamond: 11-3/4".

· 8-Diamond: 18-3/4".

· 10-Diamond: 24".

· Channel depth: 1-1/2", 2", 2-1/2".

· Length: 10', 12' or customized.

· Diamond-Strut ladder rungs: standard, reverse.

· Width: standard diamond 2-1/2", reverse diamond 1-5/8".

· Height: standard diamond 1-1/8", reverse diamond 1-5/8".

· Length: standard diamond 3', 4', 10', 12' or cut to size; reverse diamond 23-1/8".

Surface treatmentGalvanized, hot rolling, pickling.



Feature:



  • High strength to weight ratio with high bearing capacity and light weight.
  • Anti-slip, diamond opening and serrated surface for maximum slip resistance.
  • Opening design allows for drainage of fluids and debris.
  • Abrasive nosing is provided on request.
  • Simple and fast installation, little maintenance after installation.
  • Economical cost and long lifespan.


Application:

Anti-skid plates are widely used as working platforms, equipment platforms, stairways pedal, covering, bridge, walkways, filter sheet and filling support in the industries including petroleum, chemical, mining, electricity, marine exploration, electroplating, ship, water and wastewater treatment, paper making, brewing, pharmaceutical and other

Every year, industrial accidents – falling, tripping over debris and slipping on wet or greasy surfaces – cost millions of dollars in lost man-hours and production, all of which could be reduced with safety floor grating. Grip Strut™ safety metal grating helps reduce accident rates by providing a safer walking-working surface more than any other available metal grating product. Our Grip Strut™ safety floor grating serrated surface gives maximum slip protection and performance on steel flooring and metal stair treads under practically all conditions and in every direction. Our Grip Strut™ floor grating will help make your workplace safer for employees.
