Aluminum Serrated Walkway Perforated Grip Strut Treads For Safety Grating

China Aluminum Serrated Walkway Perforated Grip Strut Treads For Safety Grating supplier
Aluminum Serrated Walkway Perforated Grip Strut Treads For Safety Grating supplier Aluminum Serrated Walkway Perforated Grip Strut Treads For Safety Grating supplier Aluminum Serrated Walkway Perforated Grip Strut Treads For Safety Grating supplier Aluminum Serrated Walkway Perforated Grip Strut Treads For Safety Grating supplier

Large Image :  Aluminum Serrated Walkway Perforated Grip Strut Treads For Safety Grating

Product Details:

Place of Origin: Hebei,China
Brand Name: WANNUO
Certification: ISO9001
Model Number: ANPINGWANNUO-243

Payment & Shipping Terms:

Minimum Order Quantity: 20GP
Packaging Details: 1.wrapped with plastic film, then on a pallet 2.wrapped with plastic film then put into wodden cases 3.Packaging as the customer's request.
Delivery Time: According to the requirment
Supply Ability: 2000 Sheet/Sheets per Week
Contact Now
Detailed Product Description
Material: Aluminum Application: Stair Treads Of Office Buildings
Model Number: Customized Thickness: 1.0-3.0mm
Width: ≤1000mm Length: ≤4000mm
Holes: Alligator Mouth Type,so On Weave Style: Stamping



Aluminum Serrated Walkway Perforated Grip Strut Treads For Safety Grating



 Description:


 Aluminium Serrated Grip Strut Grating for safety stair treads offers excellent slip resistant performance in various applications. Plank grating is one of types. The material of diamond safety grating plank are commonly steels, aluminum alloy and stainless steel. Its application reduces damage and ensures safe operation of the operation workshop.
We provides maximum slip resistance in wet and oily environments. The standard serrated diamond matrix walking surface grips shoe soles securely in all directions and complies with the anti-slip values set forth in Federal.

Features:

"Maintenance-free" Open Design - allows for the quick passage of fluids, mud, snow and ice.
High Load Capacity - high strength-to-weight ratio achieved by deep section properties can serve longer spans than many comparable products.
Lightweight - planks are easy to fabricate and install.
Versatile in Application - standard width planks can be fabricated to accommodate

There are four kinds of safety gratings as the following:



  • Diamond-strut safety grating.
  • O-grip safety grating.
  • Traction-grip safety grating.
  • Interlocking safety grating.



Table 1: Specification of Diamond-Strut Safety Grating
MaterialSpan (inches)GaugeDepthStandard stair treadsStair treads with nosing





Steel

Up to 30



14 or 12 gauge

1-1/2"Diamonds (4-3/4")
 Diamonds (7")
 Diamonds (9-1/2")
 Diamonds (11-3/4")







 Diamonds (8-1/8")
Diamonds (10-1/2")

30–361-1/2"
36–421-1/2"
42–482"
AluminumUp to 420.080"



2"

Up to 480.100"
Stainless steelUp to 30316L 16 gauge



2"

Up to 36304L 16 gauge



Table 2: Specification of O-Grip Safety Grating
PatternWidthChannel DepthPre-galvanizedWeight (lb/ft.)
13 Holes24"5"11 and 13 gauge.11.8
16 Holes30"5"11 and 13 gauge13.6
16 Holes36"5"11 and 13 gauge15.9
Materials: pre-galvanized steel 11 and 13 gauge.



Table 3: Specification of Traction-Grip Safety Grating
MaterialThickness (mm)LengthWidthHeight
Mild steel2.0, 2.5, 3.0

6000 mm

120 mm
150 mm
180 mm
210 mm
240 mm
270 mm
40 mm
50 mm
75 mm
Hot-galvanized steel2.0, 2.5, 3.0
Stainless steel2.0, 2.5
Aluminum ENAW 57542.0, 2.5, 3.0



Table 4: Specification of Interlocking Safety Grating
Materialcarbon steel, mill steel
Surface treatmentHot dipped galvanized before fabrication
Gauge14 gauge, 18 gauge or 16 gauge (special)
Span length24", 30", 36", 48"
Standard Width12", 9", 7-1/2", 6"
Width with nosing7-1/2", 10-1/2", 13-1/2"
Height2-1/2"


   Application :



 --Because of its good skid resistance and beauty, it is widely used in industrial plants, production workshops and transportation facilities.
--Mainly used in petroleum, chemical, mining, power plant,marine exploration, electroplating, ship, waste water treatment,
--Paper making, brewing, pharmaceutical industries such as working platforms, equipment platforms;
--Stair treads, trench cover, bridge, walkway, filter plate, etc.
--The product is the ideal bearing materials in corrosive environment.
