Product Details:
|
| Product Name: | SS304 316 316L Marine Grade Anti Theft Black Coated Security Screen Mesh Stainless Steel Window Screen | Material: | Stainless Steel Wire 304 316 |
|---|---|---|---|
| Usage: | Anti-Mosquito, Anti Theft | Mesh: | 10 12 14 Mesh |
| Technique: | Plain Weave | Sample: | Avaliable |
| Color: | Black And Metal Color | Packing: | Paper Tube Inside+ Plywood Box+plastic Bag |
| High Light: | SS304 Security Screen Mesh,SS304 316L Security Screen Mesh,316 Security Screen Mesh |
||
Woven wire mesh or woven wire cloth, is woven by machine. It is similar to the process of weaving clothing, but made of stainless steel wire. The mesh can be made through different weave styles. The purpose is to produce solid and reliable products to adapt to various complex application environments.High precision technology makes the production cost of woven wire mesh higher, but it also has a very wide range of uses.
The wire cloth is available in both 48” and 60” widths. We can provide both full rolls and/or cut pieces depending on your requirements. The vast majority of our customers request woven mesh from 304 or 316 stainless steel, but we are also able to supply type 430 and carbon steel in most cases. Use our wire mesh chart to find the opening best suited to your application. If you need to determine the size of an existing screen, we offer metal mesh counters. They are small enough to put in your pocket and extremely easy to use. Just unfold it and set it on a piece of wire mesh. The base is a 1-inch square opening and the top is a magnifying glass. There are different units of measure marked on the interior of the base to assist you with identifying wire diameter, opening, and holes per inch.
| Material | Stainless steel 304 316 wire |
| Color | Black White Grey etc |
| Wire diameter | 0.10mm-0.26mm |
| Regular specification | 11 mesh × 0.8 mm,11 mesh × 0.9 mm, 10 mesh × 0.9 mm, 12 mesh × 0.71 mm, 14 mesh × 0.6 mm, 9 mesh × 1.0 mm. |
| Width | 2', 3', 4', 5', 6', 7' |
| Length | 30', 50', 100' and so on |
| Applications | * Stainless steel security screen can resist the thieves and intruders, so it is used in the residences, hotels and other place for security. * Due to the anti-mosquitoes and flies feature, it can be used in the windows, doors, porches and patios to prevent the harmful insects. * Stainless steel security screen can resist the corrosion, rust and fire, it can be used in the harsh environments where is corrosive, dusty. It can also be used in the fire fighting accesses. * Another importance feature of the stainless steel security screen is bullet-proof, so it can be used in military base, and other safety places. |
| Common Mesh Specifications ( Reference Data ) | |||||
| Mesh | Aperture ( mm ) | Mesh | Aperture ( mm ) | Mesh | Aperture ( mm ) |
| 2 | 13 | 18 | 1 | 70 | 0.22 |
| 3 | 6.5 | 20 | 0.9 | 80 | 0.18 |
| 4 | 5 | 24 | 0.8 | 90 | 0.16 |
| 5 | 4 | 30 | 0.6 | 100 | 0.154 |
| 6 | 3.2 | 35 | 0.5 | 120 | 0.125 |
| 8 | 2.5 | 40 | 0.45 | 150 | 0.1 |
| 10 | 2 | 45 | 0.4 | 180 | 0.09 |
| 12 | 1.6 | 50 | 0.355 | 200 | 0.075 |
| 14 | 1.43 | 55 | 0.315 | 220 | 0.07 |
| 16 | 1.25 | 60 | 0.3 | 250 | 0.063 |
1. Strong resistance to impact, anti-theft, bulletproof, anti-mosquitoes, high temperature resistance, flame retardant, high strength, strong toughness.
2. The surface luster is bright and beautiful, can be better to increase air circulation rate and the light of the sun, with smooth surface, the number of mesh standard, latitude and longitude curve are consistent.
3. Its remarkable characteristic is as hard as iron hard, anti-theft, bulletproof, home office security first place.
4. With anti-static function, no ash, good ventilation.
5. Good light transmission, with a true invisible effect.
6. Automatic filter UV protection to protect the health of the family.
7. Environment protection
Prevent from mosquitoes, flies and other insects.
Resist the thieves and intruders.
Fire proof and knife proof.
Long life and durable.
Easy to clean and install.
Resistance for corrosion and rust.
Adjust for harsh environments such as hurricane or storm.
Clear from inside and vague from outside.
Therefore, in recent years, stainless steel mesh has been widely used in hotels, public buildings, civil residences against bugs, insects, coal mines, petroleum, chemical, food, medicine, machinery manufacturing, and other industries as mines and screen.
