25um 40 Micron Sintered Metal 316l Stainless Steel Filter Disc Multilayer

25um 40 Micron Sintered Metal 316l Stainless Steel Filter Disc Multilayer
25um 40 Micron Sintered Metal 316l Stainless Steel Filter Disc Multilayer 25um 40 Micron Sintered Metal 316l Stainless Steel Filter Disc Multilayer 25um 40 Micron Sintered Metal 316l Stainless Steel Filter Disc Multilayer 25um 40 Micron Sintered Metal 316l Stainless Steel Filter Disc Multilayer

Large Image :  25um 40 Micron Sintered Metal 316l Stainless Steel Filter Disc Multilayer

Product Details:
Place of Origin: China
Brand Name: Velp
Certification: SGS CE ISO9002 BV
Model Number: Filter mesh-14
Payment & Shipping Terms:
Minimum Order Quantity: 5pcs
Price: USD 1-2 Per pcs
Packaging Details: Wooden Case / Iron Pallet + Bubble Film +Waterproof Paper +Safety Belts
Delivery Time: 15 days
Payment Terms: MoneyGram, Western Union, T/T, L/C
Supply Ability: 2000 pcs per week

25um 40 Micron Sintered Metal 316l Stainless Steel Filter Disc Multilayer

Description
Name: Stainless Steel 25um 40micron Sintered Stainless Filters Mesh Multilayer Metal Sintering Disc Material: Stainless Steel 304 310 904L 316L
Thickness: 1.7m 3.5mm Or Customized Products: Material Wire Cloth,sintered Filters,metal Tubes,baskets,discs
Usages: Petroleum,chemical Industry,pharmacy,foodstuff Pore Size: 0.5um 2um 5um 10um 15um 20um 40um 60um 90um
Feature: Anti Corrosion,temperature,wear,vibration, After Services: Video Technical Support,online Support,
High Light:

sintered metal 316l stainless steel filter disc

,

25um Stainless Steel Filter Disc

,

40 Micron sintered mesh filter disc

Stainless Steel 25um 40micron Sintered Stainless Filters Mesh Multilayer Metal Sintering Disc





Filters mesh multilayer metal sintering disc basic introduction



Sintered filter is a process in which a metal powder is passed through a special mold and is formed by high temperature sintering,By adjusting the particle size of the powder,the process conditions etc.It is possible to produce a porous metal sintered filter element having a wide range of filtration precision.



Filters mesh multilayer metal sintering disc specifications



Product name  Stainless Filters Mesh Multilayer Metal Sintering Disc
Type

Signle layer without edges

Single layer with edged

Multi layer filter disc with edge

Dutch weave filter disc

Spot welded with closed selvaged type

Spot welded without closed selvaged type

Sintered mesh filter disc

Black wire cloth disc

Material 201 304 304L 316 316L430 etc
Weave type Plain weave,twilled weave,plain dutch weave,twilled dutch weave,reverse dutch weave
Wire diameter 0.025mm--2.5mm
Thickness 1.0mm---5.0mm
Filter rate 1--200micron
Layers Single layer or multi layers
Shapes Rectangle,square,round,oval,circular,cap,waist
Usages

1.Solid/gas separation,muffler,silencer,air purification

2.Filtering oil dedusting,isolation,dust,dustproof

3.Gas-oil dissociation,gas liquid separation

4.Moistureproof,heat insulation

5.Uniform gas,well-distributed,diffuse gas or oil or heat

6.Pharmaceutical,Chemical filber

7.Filtration for high temperature environment

8.High pressure reverse wash filtering

9.Acid and alkali corrosion environment filtering



Filters mesh multilayer metal sintering disc characteristic



The material used to produce these filters is 316L stainless steel.They are made by uniaxial compaction of powder in a rigid tool with the negative shape of the part,and then sintered.The pore size is adjusted by changing the compaction pressure and the particle size of the powder.



1) High strength: After the five-layer wire mesh is sintered, it has extremely high mechanical strength and compressive strength;

2) High precision: uniform surface filtration performance can be exerted for the filtration particle size of 1-300um;

3) Heat resistance: can be used for continuous filtration from -200 degrees to up to 650 degrees;

4) Cleanability: countercurrent cleaning surface filter structure can be used, and cleaning is simple.

5) It has good permeability, high strength, no need to add support structure, no material falling off, strong corrosion resistance, easy to clean, and not easy to damage. Standard material: SUS316L.



Filters mesh multilayer metal sintering disc main purpose



1) Used as a dispersive cooling material in high temperature environment;

2) For gas distribution, liquidized bed orifice material;

3) Used for high-precision, high-reliability and high-temperature filter materials;

4) Used for high pressure backwash oil filter

5) Used for filtration of polyester, oil, food and beverage, chemical and chemical fiber products, and also for filtration of water treatment and gas.



25um 40 Micron Sintered Metal 316l Stainless Steel Filter Disc Multilayer 0

25um 40 Micron Sintered Metal 316l Stainless Steel Filter Disc Multilayer 1

25um 40 Micron Sintered Metal 316l Stainless Steel Filter Disc Multilayer 2

25um 40 Micron Sintered Metal 316l Stainless Steel Filter Disc Multilayer 3

25um 40 Micron Sintered Metal 316l Stainless Steel Filter Disc Multilayer 4
