SUS302 Stainless Steel Dutch Weave Filter Mesh 100 Micron

Large Image : SUS302 Stainless Steel Dutch Weave Filter Mesh 100 Micron

Product Details:

Place of Origin:	China
Brand Name:	VELP
Certification:	SGS
Model Number:	26

Payment & Shipping Terms:

Minimum Order Quantity:	1 roll
Price:	USD10-USD20/SQM
Packaging Details:	wooden case+waterproof paper
Delivery Time:	5-10 work days
Payment Terms:	T/T,L/C,Western Union,MoneyGram
Supply Ability:	30000 rolls month

Contact Now

SUS302 Stainless Steel Dutch Weave Filter Mesh 100 Micron

Description

Application:	Filters,Woven Wire Mesh,Protecting Mesh	Weave Style:	Dutch/Plain/Twill Weave
Type:	Wire Cloth	Technique:	Woven
Material:	SUS Stainless Steel	Wire Diameter:	Requirement
Length:	1-30m, Amd Also Can In Piece	Width:	1-2meters
Mesh:	1-500 MESH	Packing:	Paper Tube Inside+ Wodden Box +plastic Bag +
Highlight:	ss302 filter steel mesh , dutch weave filter steel mesh , 100 micron stainless steel wire mesh

Ss302 100 Micron Filter Steel Mesh In Roll And Piece Dutch Weave

Product Specifications

Attribute	Value
Application	Filters, Woven Wire Mesh, Protecting Mesh
Weave style	Dutch/Plain/Twill Weave
Type	Wire Cloth
Technique	Woven
Material	SUS stainless steel
Wire diameter	Requirement
Length	1-30m, and also can be in piece
Width	1-2 meters
Mesh	1-500 MESH
Packing	Paper tube inside + wooden box + plastic bag

Food Grade AISI SUS 304 316 316L Stainless Steel Filter Wire Mesh

High-density stainless steel woven mesh, also known as stainless steel wire mesh, is manufactured using superior stainless steel wire under specific high-temperature process conditions. The wire is drawn to specific dimensions and then woven in controlled environments to ensure quality and precision.

Available Specifications

Mesh Count: 1-3200 mesh
Width: 0.1-8 meters
Filtering Precision: 5-300μm
Materials: SUS302, 304, 304L, 316, 316L, 310, 310S dual-phase steel
Weave Methods: Plain weave, twill weave, dense weave, and special-shaped weave

Technical Specifications

Product Name	Woven Wire Mesh, Wire Cloth
Stainless Steel Grade	304, 304L, 316, 316L, 310s, 904L, 430, etc
Special Material Options	Inconel, Monel, Nickel, Titanium, etc
Wire Diameter Range	0.02 - 6.30mm
Hole Size Range	1 - 3500mesh
Weave Types	Plain Weave, Twill Weave, Dutch Weave, Plain Dutch Weave, Twill Dutch Weave, Reverse Dutch Weave, Multiplex Weave
Mesh Width	Standard less than 2000 mm
Mesh Length	30m rolls or cut to length, minimum 2m
Production Standards	ASTM E2016 - 20
Certification	ISO9001: 2015

Detailed Mesh Specifications

Mesh/Inch	Wire Diameter (Inch)	Wire Diameter (MM)	Aperture (Inch)	Aperture (MM)	Open Area	Weight (LB)/100 Square Foot
1x1	.080	2.03	.920	23.37	84.6	41.1

Key Features

Excellent alkali and acid resistance
Super precision with uniform wire diameter and aperture
Easy to install and clean
Customizable specifications (wire diameter, aperture, thickness)
Low and high temperature resistance

Applications

Our stainless steel woven mesh is widely used in various industries including:

Marine applications
Pharmaceutical and food processing
Rubber and plastic manufacturing
Chemical plants
Automotive industry
Oil industry and cereal sifters
Absorption, evaporation and filtration processes
Air filtration in vehicles

Packaging

Woven wire mesh is available on rolls or cut to size. We provide fine and strict packaging to ensure the goods arrive undamaged. Standard packaging includes paper tube inside, wooden box, and plastic bag, with custom packaging options available.
