Anti Corrosion Stainless Wire Mesh SS201 SS304 SS306 SS316
Product Specifications
| Attribute |
Value |
| Name |
SS201 SS304 SS306 SS316 stainless steel wire mesh phasix mesh |
| Weave style |
Dutch, Plain, Twill Weave |
| Width |
0.2m-3m or customized |
| Length |
1m-50m or customized |
| Feature |
Anti corrosion |
| Color |
Silver |
| Hole shape |
Square Hole |
| Advantage |
Factory direct sale, best material |
| Mesh count |
1-900mesh |
| Packing |
Plastic film + iron pallet |
Stainless Steel Mesh Introduction
High-density stainless steel woven mesh, also known as stainless steel wire mesh or square hole woven mesh, is manufactured using superior stainless steel wire under specific high-temperature process conditions. The wire is drawn to precise specifications and woven in dust-free, clean workshops using specialized knitting machines.
Available in mesh counts ranging from 1 to 3200 mesh, with widths from 0.1 to 8 meters and filtering precision of 5-300μm. Materials include SUS302, 304, 304L, 316, 316L, 310, 310S dual-phase steel, with weaving methods including plain weave, twill weave, dense weave, and special-shaped weave.
Material Specifications
Product Name: Woven Wire Mesh, Wire Cloth
Stainless Steel Grades: 304, 304L, 316, 316L, 310s, 904L, 430
Special Material Options: Inconel, Monel, Nickel, Titanium
Wire Diameter Range: 0.02 - 6.30mm
Hole Size Range: 1 - 3500mesh
Weave Types: Plain Weave, Twill Weave, Dutch Weave, and variations
Production Standards: ASTM E2016 - 20
Certification: ISO9001:2015
Technical Specifications
| Mesh/Inch |
Wire Diameter |
Aperture |
Open Area |
Weight (LB)/100 Square Foot |
| 1x1 |
.080" (2.03mm) |
.920" (23.37mm) |
84.6% |
41.1 |
| 2X2 |
.063" (1.60mm) |
.437" (11.10mm) |
76.4% |
51.2 |
| 635X635 |
.0008" (.0203mm) |
.0008" (.0203mm) |
25.0% |
2.63 |
Key Features
- Weaving process creates no stress-induced weaknesses
- Point contact allows freer screening and reduced binding
- Excellent corrosion, abrasion and heat resistance
- Aesthetic appeal for architectural applications
- Hygienic characteristics suitable for food and pharmaceutical industries
- Cost-effective solution for industrial applications
Applications
High-density stainless steel woven mesh is widely used in mining, petroleum, chemical, food, pharmaceutical, and machinery manufacturing industries. Applications include screening and filtering under acid/alkali conditions, mud mesh in petroleum industry, screen filters in chemical processing, pickling nets in electroplating, and gas/liquid filtration systems.
Packaging
Available in rolls or cut to size with fine packaging to prevent damage during shipping. Standard packaging includes plastic film and iron pallet, with custom options available.
