1.5mm Stainless Steel Woven Wire Mesh 10 50 100 150 200 250 500 600 Micron
Product Specifications
Product Name:
10 50 100 150 200 250 500 600 micron stainless steel flour mesh standard Laboratory Test Sieve/soil sieve/sand sieve
Application:
Laboratory Test Sieve/soil sieve/sand sieve
Material:
Stainless Steel 304 316 304L 316L 409, 430, 439
Advantage:
In stock product
Wire diameter:
0.02 - 1.5mm
Width:
1M,1.5M,1.2M, OR as customized
Length:
30m, 20m, 15m, or as required
Food Grade AISI SUS 304 316 316L Stainless Steel Filter Wire Mesh
Stainless Steel Mesh Introduction
Woven wire mesh or woven wire cloth is machine-woven using various weave styles to create durable products for complex application environments. While production costs are higher due to precision technology, the material offers exceptional versatility.
Primary materials include 304, 316, 310, 904L, and 430 stainless steel grades, with 304 and 316 being the most popular for their cost-effectiveness and broad compatibility. Specialized materials like Inconel, Monel, Titanium, Nickel, and Silver meshes are available for demanding environments.
Material Specifications
| Product Name |
Woven Wire Mesh, Wire Cloth |
| Stainless Steel Grade |
304, 304L, 316, 316L, 310s, 904L, 430, etc |
| Special Material Options |
Inconel, Monel, Nickel, Titanium, etc |
| Wire Diameter Range |
0.02 - 6.30mm |
| Hole Size Range |
1 - 3500mesh |
| Weave Types |
Plain Weave, Twill Weave, Dutch Weave, Plain Dutch Weave, Twill Dutch Weave, Reverse Dutch Weave, Multiplex Weave |
| Mesh Width |
Standard less than 2000 mm |
| Mesh Length |
30m rolls or cut to length, minimum 2m |
| Mesh Type |
Rolls and sheets available |
| Production Standards |
ASTM E2016 - 20 |
| Certification |
ISO9001: 2015 |
Technical Specifications
| Mesh/Inch |
Wire Diameter (Inch/MM) |
Aperture (Inch/MM) |
Open Area |
Weight (LB)/100 Square Foot |
| 1x1 |
.080 / 2.03 |
.920 / 23.37 |
84.6 |
41.1 |
Mesh Count and Micron Size
Mesh Count refers to the number of holes per inch, while Micron Size measures hole dimensions in micrometers. These specifications determine filtering performance:
- Higher Mesh Count = Smaller holes
- Larger Micron Size = Larger holes
Key Features
Excellent corrosion resistance
Low thermal expansion coefficient
High thermal conductivity
Uniform screen thickness
Ideal for chemical processing and seawater desalination
Applications
Widely used across multiple industries including petroleum, chemical processing, environmental protection, mining, aerospace, paper manufacturing, electronics, metallurgy, food processing, and pharmaceuticals.
Packaging
Available in rolls or custom-cut sizes with protective packaging to prevent damage during shipping.
