Product Details:
|
| Product Name: | Stainless Steel Dust Proof Window Screen Decorative Window Screen Electric Window Screens | Material: | Stainless Steel Wire201 304 |
|---|---|---|---|
| Application: | Sound Insulation, Heat Insulation, Insect Resistant, Dustproof, Windproof | Wire Diameter: | 0.21mm, 0.23mm, 0.25mm |
| Advantage: | Corrosion, Abrasion And Heat Resistance. | Technique: | Plain Weaving |
| Width: | 80cm, 90cm, 100cm, 120cm | Length: | 30m, 50m, 100m |
| High Light: | dust proof fly screen metal mesh,201 stainless fly screen metal mesh,dust proof security door wire mesh |
||
Stainless steel insect mesh is made of the basic stainless alloy (Type 304). It is the most durable of the materials available for insect mesh and has excellent resistance to corrosion.Stainless steel insect mesh keeps out flies, wasps, bees, mosquitoes and other insects.
Woven for optimization of 304 stainless steel material, is not easy to rust and corrosion resistance, oxidation resistance is strong, stable performance, stainless steel net uniform aperture high smoothness, surface level off is smooth, without burr, simple maintenance, strong tensile toughness, use cycle is long, high intensity, mesh accurate thickness, the same production with good reproducibility, source manufacturer, factory direct supply, quality guaranteed, Complete mesh specifications, support customization.
|
Product Name
|
Woven Wire Mesh, Wire Cloth
|
|
Stainless Steel Grade
|
Stainless Steel 201,304,
|
|
Special Material Options
|
Inconel, Monel, Nickel, Titanium, etc
|
|
Wire Diameter Range
|
0.21mm,0.23mm,0.25mm |
|
Hole Size Range
|
1 - 3500mesh
|
|
Weave Types
|
Plain Weave
Twill Weave
Dutch or 'Hollander' Weave
Plain Dutch Weave
Twill Dutch Weave
Reverse Dutch Weave
Multiplex Weave
|
| Color |
natural color,black |
|
Mesh Width
|
80cm,90cm,100cm,120cm |
|
Mesh Length
|
30m,50m,100m |
|
Mesh Type
|
Rolls and sheets are available
|
| Common Mesh Specifications ( Reference Data ) | |||||
| Mesh | Aperture ( mm ) | Mesh | Aperture ( mm ) | Mesh | Aperture ( mm ) |
| 2 | 13 | 18 | 1 | 70 | 0.22 |
| 3 | 6.5 | 20 | 0.9 | 80 | 0.18 |
| 4 | 5 | 24 | 0.8 | 90 | 0.16 |
| 5 | 4 | 30 | 0.6 | 100 | 0.154 |
| 6 | 3.2 | 35 | 0.5 | 120 | 0.125 |
| 8 | 2.5 | 40 | 0.45 | 150 | 0.1 |
| 10 | 2 | 45 | 0.4 | 180 | 0.09 |
| 12 | 1.6 | 50 | 0.355 | 200 | 0.075 |
| 14 | 1.43 | 55 | 0.315 | 220 | 0.07 |
| 16 | 1.25 | 60 | 0.3 | 250 | 0.063 |
Mesh, Mesh Count, And Micron Size:
Mesh Count and Micron Size are very important terms in the wire mesh industry.
The Mesh count is actually the number of holes in an inch length, so the smaller mesh count,the hole is bigger.The Micron Size actually means the hole size.Can be in miron or mm.
In order to make it easier for people to understand the number of the holes of the wire mesh, these two specifications are usually used together. This is the key component of specifying the wire mesh. The Mesh Count determines the filtering performance and function of the wire mesh.
Micron Size = size of mesh hole. (larger the micron size, larger the mesh hole)
More intuitive expression: Mesh Count = number of mesh hole. (larger the mesh count, the smaller the mesh hole).
Excellent corrosion resistant ability.
Lower thermal expansion coefficient.
High thermal conductivity.
Widely used in chemical.
Seawater desalination equipment.
Uniform screen thickness.
Stainless Steel Woven Mesh Applications
Therefore, in recent years, stainless steel mesh has been widely used in coal mines, petroleum, chemical, food, medicine, machinery manufacturing, and other industries as mines and screen.
