10 12 14 Mesh Stainless Steel Security Window Screen Mosquito Net Wire Mesh
Product Specifications
| Attribute | Value |
| Product name | 10 12 14 Mesh Stainless Steel Security Window Screen Mosquito Net Wire Mesh |
| Material | Stainless Steel 201 304 |
| Mesh count | 10 12 14 Mesh |
| Length | 30m, 50m, 100m |
| Advantage | Anti-Theft, Mosquito-Proof |
| Technique | Plain weave, Twill Weave |
| Width | 100cm, 120cm |
| HS code | 7314140000 |
Stainless Steel Mesh Introduction
Stainless steel insect mesh is made of the basic stainless alloy (Type 304). It is the most durable of the materials available for insect mesh and has excellent resistance to corrosion. Stainless steel insect mesh keeps out flies, wasps, bees, mosquitoes and other insects.
Woven for optimization of 304 stainless steel material, is not easy to rust and corrosion resistance, oxidation resistance is strong, stable performance, stainless steel net uniform aperture high smoothness, surface level off is smooth, without burr, simple maintenance, strong tensile toughness, use cycle is long, high intensity, mesh accurate thickness, the same production with good reproducibility, source manufacturer, factory direct supply, quality guaranteed, Complete mesh specifications, support customization.
Product Applications
- Stainless steel security screen can resist thieves and intruders, making it ideal for residences, hotels and other security-sensitive locations
- Effective anti-mosquito and fly protection for windows, doors, porches and patios
- Resistant to corrosion, rust and fire, suitable for harsh environments including corrosive and dusty areas, as well as fire fighting accesses
- Bullet-proof properties make it suitable for military bases and other high-security locations
Stainless Steel Woven Mesh Material Specifications
| Product Name | Woven Wire Mesh, Wire Cloth |
| Stainless Steel Grade | Stainless Steel 201, 304 |
| Special Material Options | Inconel, Monel, Nickel, Titanium, etc |
| Wire Diameter Range | 0.21mm, 0.23mm, 0.25mm |
| Hole Size Range | 1 - 3500mesh |
| Weave Types | Plain Weave, Twill Weave, Dutch or 'Hollander' Weave, Plain Dutch Weave, Twill Dutch Weave, Reverse Dutch Weave, Multiplex Weave |
| Color | Natural color, black |
| Mesh Width | 80cm, 90cm, 100cm, 120cm |
| Mesh Length | 30m, 50m, 100m |
| Mesh Type | Rolls and sheets available |
Common Mesh Specifications (Reference Data)
| Mesh | Aperture (mm) | Mesh | Aperture (mm) | Mesh | Aperture (mm) |
| 2 | 13 | 18 | 1 | 70 | 0.22 |
| 3 | 6.5 | 20 | 0.9 | 80 | 0.18 |
| 4 | 5 | 24 | 0.8 | 90 | 0.16 |
| 5 | 4 | 30 | 0.6 | 100 | 0.154 |
| 6 | 3.2 | 35 | 0.5 | 120 | 0.125 |
| 8 | 2.5 | 40 | 0.45 | 150 | 0.1 |
| 10 | 2 | 45 | 0.4 | 180 | 0.09 |
| 12 | 1.6 | 50 | 0.355 | 200 | 0.075 |
| 14 | 1.43 | 55 | 0.315 | 220 | 0.07 |
| 16 | 1.25 | 60 | 0.3 | 250 | 0.063 |
Mesh Count and Micron Size
Mesh Count and Micron Size are very important terms in the wire mesh industry. The Mesh count is the number of holes in an inch length (smaller mesh count means larger holes). The Micron Size refers to the hole size, measured in microns or millimeters.
These specifications are typically used together to clearly describe wire mesh properties. The Mesh Count determines the filtering performance and function of the wire mesh.
Micron Size = size of mesh hole (larger micron size means larger mesh holes). Mesh Count = number of mesh holes (larger mesh count means smaller mesh holes).
Stainless Steel Woven Mesh Advantages
- 304 stainless steel construction
- Uniform aperture with smooth net surface
- High strength and toughness
- Complete specifications with customization support
- Excellent corrosion and pressure resistance
- Superior filtering performance with long service life
Key Features
- Strong resistance to impact, anti-theft, bulletproof, anti-mosquitoes
- High temperature resistance and flame retardant properties
- High strength with strong toughness
- Bright, attractive surface finish that enhances air circulation and sunlight penetration
- Smooth surface with standard mesh counts and consistent latitude/longitude curves
- Exceptional durability with iron-hard strength for superior security applications
Customization Options
The wire cloth is available in both 48" and 60" widths. We provide full rolls and/or cut pieces to meet your requirements. While most customers request 304 or 316 stainless steel woven mesh, we can also supply type 430 and carbon steel options.
Use our wire mesh chart to find the optimal opening size for your application. For identifying existing screen specifications, we offer convenient metal mesh counters with measurement guides for wire diameter, opening size, and holes per inch.
