304 316 Stainless Steel Woven Wire Mesh 100 120 Mesh for Industrial Filtration

Large Image : 304 316 Stainless Steel Woven Wire Mesh 100 120 Mesh for Industrial Filtration

Product Details:

Place of Origin:	Hebei Province China
Brand Name:	Velp
Certification:	SGS BV ISO
Model Number:	stainless steel wire mesh 007

Payment & Shipping Terms:

Minimum Order Quantity:	10sqm
Price:	USD10-USD20/SQM
Packaging Details:	wooden box
Delivery Time:	10-15days
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:	3000sqm/day

Contact Now

304 316 Stainless Steel Woven Wire Mesh 100 120 Mesh for Industrial Filtration

Description

Name:	100 120 Mesh Stainless Steel Woven Wire Fine Screen Wire Mesh	Material:	304/316 Stainless Steel
Wire Diameter:	0.025-1.6	Mesh Count:	2-400
Aperture:	0.0385-10.8	Weave Style:	Plain Weave/ducth/twilled
Mesh Width:	1m/1.2m/1.5m Or Customized	Length:	30m/roll Or Customized
Applications:	Filter/sieving/petroleum/chemical Industry	Keywords:	Acid Resisting
Highlight:	Fine Screen Stainless Steel Wire Mesh , Woven Wire Stainless Steel Wire Mesh , stainless steel woven wire 100 mesh

100 120 Mesh Stainless Steel Woven Wire Fine Screen Wire Mesh

Product Specifications

Attribute	Value
Name	100 120 Mesh Stainless Steel Woven Wire Fine Screen Wire Mesh
Material	304/316 stainless steel
Wire diameter	0.025-1.6
Mesh count	2-400
Aperture	0.0385-10.8
Weave Style	plain weave/ducth/twilled
Mesh width	1m/1.2m/1.5m or customized
Length	30m/roll or customized
Applications	filter/sieving/petroleum/chemical industry
Keywords	Acid Resisting

Product Description

Stainless steel wire mesh is widely used in industrial filtration applications, commonly referred to as stainless steel filter mesh. The material's inherent properties of acid resistance, alkali resistance, high temperature tolerance, and wear resistance make it an indispensable filtration solution for numerous industrial applications.

Our stainless steel wire mesh filters are available in various opening sizes and can be used alongside perforated metal and expanded metal. These filters are particularly suitable for demanding environmental conditions. We specialize in custom fabrication of stainless steel filters in single or multiple layers of woven wire mesh, available in plain, twill, plain dutch, and reverse dutch twill weaves.

Technical Parameters

Mesh	Wire diameter(mm)	Opening(mm)	Material(AISI)
7*7	1.0	2.63	304 or 316
10*10	0.6	1.94	304 or 316
12*12	0.5	1.62	304 or 316
16*16	0.4	1.19	304 or 316
18*18	0.35	1.06	304 or 316
20*20	0.35	0.87	304 or 316
24*24	0.26	0.8	304 or 316
30*30	0.3	0.55	304 or 316
35*35	0.17	0.56	304 or 316
40*40	0.23	0.4	304 or 316
50*50	0.2	0.31	304 or 316
60*60	0.15	0.27	304 or 316
70*70	0.12	0.24	304 or 316
80*80	0.13	0.19	304 or 316

Key Advantages

Corrosion Resistance: Highly resistant to rust and corrosion, ideal for harsh environments including marine, chemical, and outdoor applications.
Strength and Durability: Offers high tensile strength and can withstand extreme temperatures, pressure, and mechanical stress.
Versatility: Available in various weaves (plain, twill, Dutch) and mesh sizes, customizable for specific applications.

Applications

Our stainless steel wire mesh is used for:

Filtering oil and gas liquid separation
Uniform gas distribution and heat diffusion
High temperature environment filtration
High pressure reverse wash filtering
Acid and alkali corrosion environment filtering

Widely used in food processing, aviation, transportation infrastructure, water conservancy projects, slope protection, aquaculture, metallurgical machinery, sewage treatment, and other industrial fields.

About Our Company

Our 20,000 square meter factory located in Anping County, China features three specialized production workshops. We maintain three strategically located factories (totaling over 5,000 square meters) to ensure prompt response to inquiries and efficient order fulfillment. Each facility offers comprehensive design, engineering, sales, and fabrication services with complete inventories to meet project deadlines.
