High Durability Stainless Steel 304 100 150 Mesh Woven Wire Mesh Screen Filter
Stainless Steel Woven Mesh Introduction
At some stage of production, many industries needs to sieve, screen or grade their raw materials or products. In support of this, there is nothing quite as superior as woven wire mesh as a filtration medium. It is a highly durable material, being both resistant to corrosion and very strong. Mesh also offers excellent open areas. Likewise, it is supplied in many specifications. We also supply stainless steel woven mesh for many other uses.
Specification
| Product Name: |
Woven Wire Mesh, Wire Cloth |
| Stainless Steel Grade: |
304, 304L, 316, 316L, 310s, 904L, 430, etc
|
| Special Material Options: |
Inconel, Monel, Nickel, Titanium, etc |
| Wire Diameter Range: |
0.02 - 6.30mm |
| Hole Size Range: |
1 - 3500mesh |
| Weave Types: |
Plain Weave, Twill Weave, Dutch or 'Hollander' Weave, Plain Dutch Weave Twill Dutch Weave, Reverse Dutch Weave, Multiplex Weave |
| Mesh Width: |
Standard less than 2000 mm |
| Mesh Length: |
30m rolls or cut to length, minimum 2m |
| Mesh Type: |
Rolls and sheets are available |
The product range:
We maintain huge stocks of mesh. Rolls of woven wire stainless steel mesh are readily available in a wide range of mesh specifications. We keep stocks with a mesh count from 2 mesh (with a 1.6 mm wire diameter) through to 500 mesh (with a 0.025 mm wire diameter). These provide apertures from 11.1 mm down to 0.025 mm (25 microns). Primarily of stainless steel, woven wire mesh stocks are also held in a range of other materials.
These include mild steel, brass, phosphor bronze, copper, monel, aluminium . Furthermore, we stock Type 304 and Type 316 stainless steel mesh in most specifications.
Types of weave:
Mesh can be woven in several ways. The largest demand is for plain weave woven mesh. For the finer meshes, twilled weave woven mesh is available from our stocks. We also supply plain dutch and twilled dutch weaves. Of note, the dutch weaves allow for the finest filtration, down to 0.006 mm (6 microns).
Product Applications:
High-density Stainless steel woven mesh is widely used in mining, petroleum, chemical, food, medicine, machinery manufacturing, and other industries. It is mainly used for screening and filtering under acid and alkali environmental conditions. It is used as a mud mesh in the petroleum industry, as a screen filter in the chemical and chemical fiber industry, and electroplating. Industrial use for pickling nets, gas, liquid filtration, and other media separation.
Packing
Below pictures is for our existed clients, stainless steel weave wire mesh help them solve a lot of issues in industry of filtration, sieve, chemical, industrial, oil etc.
We can cut any size of width according to clients’ request, making stainless steel screen mesh conveniently to use for clients. Before loading / delivery products, we will package stainless steel screen mesh by kraft paper, and then package into the wooden case. In order to Protect stainless steel from damage.
woven bag + safety belt + pvc film + wooden case
